introduce:
WELLDE Model T8014A T8016A Boring diameter Φ65-Φ140mm Φ80-Φ165mm Max.boring depth 300mm 400mm Spindle speed 250,380 r/min 200,300 r/min Spindle feed 0.11 mm/r 0.12 mm/r Spindle rapid reset 636 mm/min 780 mm/min Voltage 220V / 380V 220V / 380V Motor Output 0.25/0.37kw 0.25/0.37kw Motor speed 1440 r/min 1440 r/min
specifications:
Model | ||
Boring diameter | Φ65-Φ140mm | Φ80-Φ165mm |
Max.boring depth | 300mm | 400mm |
Spindle speed | 250,380 r/min | 200,300 r/min |
Spindle feed | 0.11 mm/r | 0.12 mm/r |
Spindle rapid reset | 636 mm/min | 780 mm/min |
Voltage | 220V / 380V | 220V / 380V |
Motor Output | 0.25/0.37kw | 0.25/0.37kw |
Motor speed | 1440 r/min | 1440 r/min |
Overall dimensions | 320×330×850 mm | 320×330×850 mm |
Package size | 540x470x1030 mm | 500x490x1270 mm |
Machine weight | 62kg | 85kg |
